Permanent magnet synchronous motor is an efficient and compact synchronous motor that uses permanent magnets to generate a magnetic field and interacts with the rotating magnetic field generated by the stator winding to rotate. Permanent magnet synchronous motors have become the main driving motors, mainly due to their significant advantages in multiple aspects. The following is a detailed analysis of these advantages:

1、Efficient performance

① High efficiency: During operation, permanent magnet synchronous motors can significantly improve efficiency due to the synchronous operation of the rotor and stator magnetic fields after the installation of permanent magnets, without rotor resistance and hysteresis losses. Compared with asynchronous motors, permanent magnet synchronous motors can save energy at any speed point, especially at lower speeds.

② High power factor: There is no induced current excitation in the rotor of the permanent magnet synchronous motor, and the stator winding presents a resistive load, resulting in a power factor of nearly 1 for the motor. This not only reduces the stator current and improves the efficiency of the motor, but also improves the quality factor of the power grid, reduces the losses of the transmission and transformation lines, and lowers the transmission and transformation capacitance and investment costs.

2、Superior physical properties

① Small size and light weight: With the application of permanent magnet materials, the power density of permanent magnet synchronous motors has been improved. Compared with asynchronous motors of the same volume, permanent magnet synchronous motors can reduce their volume, weight, and materials by about 30%. This makes permanent magnet synchronous motors have significant advantages in fields such as new energy vehicles that have strict requirements for volume and weight.

② Strong bearing capacity: Permanent magnet synchronous motors have hard mechanical characteristics and strong resistance to torque disturbances caused by load changes. Its instantaneous torque can reach more than three times the rated torque, suitable for working conditions with large changes in load torque.

3、Widely applicable scenarios

① New energy vehicles: In the field of new energy vehicles, permanent magnet synchronous motors have become one of the most widely used drive motors due to their significant advantages in power to mass ratio, volume, mass, output torque, maximum speed, and braking performance.

② Other fields: Permanent magnet synchronous motors are also widely used in wind power generation, ship propulsion, industrial automation, and other fields. Its efficient, reliable, and compact characteristics have led to an increasing demand for permanent magnet synchronous motors in these fields.

4、Policy support and environmental advantages

With the global emphasis on energy conservation and emission reduction, governments around the world have introduced relevant policies to support the research and application of high-efficiency motors. As one of the representatives of efficient motors, permanent magnet synchronous motors have received key support and promotion from the government. Meanwhile, the efficient operation of permanent magnet synchronous motors also reduces energy consumption and emissions, meeting the requirements of environmental protection and sustainable development.

5、Technological development trends

With the continuous development and upgrading of technology, the performance of permanent magnet synchronous motors will be further improved. For example, by optimizing the material and structure of permanent magnets, the power density and efficiency of motors can be improved; By improving the control strategy, the dynamic response speed and stability of the motor can be enhanced. These technological upgrades will further promote the application and development of permanent magnet synchronous motors in various fields.

In summary, permanent magnet synchronous motors have become one of the main driving motors due to their high efficiency performance, superior physical characteristics, wide application scenarios, policy support, environmental advantages, and technological development trends.
